LED flasher does not work need help.

Status
Not open for further replies.
1. I ready don't spend time typing this stuff up for my health. As I stated already - I don't know anything additional:

View attachment 116285

2. Why would you remove the LED and leave the module powered? That makes ZERO sense.


I have a photo conductive cell the size of a quarter with no part number and NO SUN to test it. Rain and over cast most of the winter if I could get 5 minutes of sunlight I could learn how it works. If it becomes high resistance in the sun then maybe I can wire it in series with the LED that would be the same thing as removing the LED from a running circuit. Maybe it be better wired in a different part of the circuit. I will look at datasheet for 1 with a part number.

I wish I had a simulator that would be great last time I tried to buy one it was $500. There use to me an online simulator with limited use I used it some the only thing I was every able to use it on was 555 ICs. I wired circuits like my TTL book shows the signal never matched the book.

All PNP transistors are not equal. Some from old TVs will not work in this circuit even though meter says transistor is good. I ordered 100 PNP transistors.

Found a simulator that looks like it works but i can't find transistors yet. Need to go, be back later.

Last edited:
I often take my laptop to McDonald's, buy lunch and work away for a while.

This, I think is the guy that has asked a couple of times how he can get free WI-FI from McDonalds from his house, without going there. How to make a long range WI-FI antenna.

All the simulators want me to register. One let me make a circuit with 1 transistor and 1 resistor then it refused to let me continue until I register.

An LDR is the size of a pencil, not huge like a quarter. It is about 600 ohms in bright sunlight and a few Megohms in the dark but an LED with a 6V supply and a 600 ohm series current limiting resistor will be fairly dim. The LDR can turn on an NPN transistor that can turn on a much brighter LED. The LDR can turn off a PNP transistor that can turn off the LED when there is bright sunlight on the LDR.

All the simulators want me to register. One let me make a circuit with 1 transistor and 1 resistor then it refused to let me continue until I register.
gary, have you tried TINA TI? (Texas Instruments SIM).

The free version has, as you'd expect, limitations, but it's a start... :happy:.

An LDR is the size of a pencil, not huge like a quarter. It is about 600 ohms in bright sunlight and a few Megohms in the dark but an LED with a 6V supply and a 600 ohm series current limiting resistor will be fairly dim. The LDR can turn on an NPN transistor that can turn on a much brighter LED. The LDR can turn off a PNP transistor that can turn off the LED when there is bright sunlight on the LDR.

Here it is. It is actually a bit larger than a quarter. I have had this 40 years. OK so this device is called an LDR good to know, it measures 40,000. ohms with no light. With a 100 watt incandescent light bulb shining on it, it measures 40 ohms. With my police spot light shining on it, it measures 39 ohms. What will SUN light do to it? This is backwards low resistance in sunlight will turn the blinker circuit ON. I need a reversing circuit, that uses less power than 1 LED blinking 15 hours.

**broken link removed**

Last edited:
A suitable small LDR between emitter and base of a transistor, plus a high value resistor from base to power, form an on-when-dark switch.

Or use the LDR to turn on a transistor that in turn grounds the base of another transistor, eg. on in the LED multivibrator.

For low power consumption it needs a small, low-leakage LDR (that won't take much current when dark) and a high value bias resistor, as power is drawn through that resistor in the daylight / device off state.


The old versions of these roadworks warning lights had a simple two transistor schmitt trigger with a resistor and LDR divider connected to a capacitor at the input that turned the filament lamp on or off.
https://encrypted-tbn0.gstatic.com/...WGR_WhFPuo0_TEdXW2CKkf05Z1kto3VXkn6TxqoGeJXLP

They stay off when ambient light is high enough, or turn on when it gets dark - then immediately turn themselves off again, until the RC network recharges and reaches the schmitt trigger threshold again, so they flash when its dark.

My old solar garden lights used an LDR the size of a pencil. They failed in about 2 years because they were Chinese and got sunburned.
Your LDR or a smaller newer one can turn off a transistor when sun shines on it then the transistor turns on your LED flasher circuit when it is dark.

I have learned if I cut a 2.5" x 3.5" blocks of wood from 2x4 boards then paint them black, drill hole front & center, attach it to a tree with a screw, it looks like a camera from 5 to 40 ft away in the dark with a flash light. I also learned the 1 light red LED flasher is more noticeable in the dark the the 2 light red LED flasher. If I replace 1 of the 2 red LEDs on the 2 light flasher with, yellow, green or white LED it becomes more noticeable than the 1 light LED flasher. Next thing I learned if I set the 2 AA battery pack on top of the fake camper with the 2 LED lights hanging over the front of the fake camera it looks like some type security camera with a red & yellow flashing light in the dark. Turns out the 2 light multi color LED flasher is more noticeable after dark than a single light LED flasher. I have not tried a single white LED flasher yet it may be the most noticeable after dark.
