digital voice synthesizer ic

Status
Not open for further replies.

mozikluv

New Member
:D hi guys,

anybody familiar with this ic? the parts number have been erase and replace with their own number, here is the pin out:

pn 1 - Wosc 1
2 - Wosc 0
3 - S1 (connected to Qa of 74C192)
4 - S2 (connected to Qb of 74C192)
5 - Sel (open)
6 - NRL (tied to gnd)
7 - ROB (tied to gnd or left open)
8 - Rosc 1 (open)
9 - Rocs 0 (open)
10 - DAT (open)
11 - Vdd
12 - AVDD (analog Vdd)
13 - IN (mike input)
14 - AVSS (analog Vss)
15 - Vss
16 - RDout

can anyone tell me whats the real part number and the meaning of the pin designation of pin # 3, 4, 5, 6, 7, 10, & 16 ?

thanx

:D


mozikluv

New Member
ic part number

:D

a friend told me its RTS0072, but does not know who the manufacturer of this ic. can anyone provide the datasheet of this ic?

thanx

:D


mozikluv

New Member
synthesizer ic

:D hi exo,

thanx for the response, learning something out of your field is something learned :wink: :D :D


dinesh_aurum

New Member
Re: ic part number

mozikluv said:
:D

a friend told me its RTS0072, but does not know who the manufacturer of this ic. can anyone provide the datasheet of this ic?

thanx

:D
:D



hi, i am dinesh from india

rts0072 is manufactured by realtek there other man. making the same i.c.

which is pin 2 pin comatible

for details you can contact me
