Darth Vader Toaster

micr0man

Member

• Jun 30, 2011

• #21

If you wanted you could also get a super cap with thick leads coming off, I guess its similar to using camera flash banks. This link may help: https://www.instructables.com/community/Electrolytic-vs-supercap-for-CD-spotwelder/



killivolt

Well-Known Member

• Jun 30, 2011

• #22

Dark Side of Toast

Well I ended up going the silver solder route. After cleaning it good with a file it finally took.

Thanks for all the help. kv



Attachments

• The dark side of toast.jpg

  466.3 KB · Views: 312

Last edited: Jun 30, 2011

S

shokjok

Member

• Sep 8, 2012

• #23

Where is the power feed to the PTA2511P IC? The VCC pin shows no source feed, that could be your problem unless it is a voltage supplied by the IC to the circuit. Regardless, this IC has no power source and could be the root of the problem.



K

KeepItSimpleStupid

Well-Known Member

Most Helpful Member

• Sep 8, 2012

• #24

Look again, The voltage divider of R8 and R15 regulated by Vz1 to 3.9 V is the power source.
