Cricket Communicating Thermostat LED & LCD drawings

[William At MyBlueRoom]

Here's an early release of the concept layout for the Cricket Communicating Thermostat. Either the LED & LCD version can be built on the same PCB (you turn it sideways).

If you want the 3D drawings email me at wrichardson@myblueroom.com and I'd be happy to send them to you. You'll need the free sketchup viewer to see them though. www.sketchup.com

I will post them when they are complete, for now its just for reference.



[William At MyBlueRoom]

Here's an early drawing of my first (PIC16F877A) design. Lots of relays (5) and an LCD display. Also used a MAX3160 Multiprotocol Transceiver.

The new version is more economical, if you want more relays it (the Cricket) was designed to slave to the Ladybug (also on my site).
