New Monitor conversion help

Status
Not open for further replies.

underwaterchippie

New Member
Hello dear friends,

I have an old CNC machine and the touchscreen monitor is connected directly into the motherboard using this cable (photo attached) . It seems to be a 24-pin JST connector… would you guys know or recommend a converter to use with a modern monitor - VGA or usb connection? I don’t have the schematics of this board!

Hope to hear from you! Kind Regards,


Attachments

  • 109814CA-7996-46DC-AA2D-93313B80E000.jpeg
    886.1 KB · Views: 187
Sort by date Sort by votes
I don't have any hope on the "touch screen" part working again.
Maybe on the monitor part.
Do you have any test equipment like an oscilloscope?
We don't know what type of monitor. Do you have any information? It might not be VGA but CGA or EGA or custom.

Upvote 0 Downvote
Hi Ron,
Thanks for your reply!
I don't have an oscilloscope unfortunately, however I managed to find some good information about the monitor after finding the manufacturers part number. I have attached here the monitor specs as well as some photos of the connectors wiring sequence. I would appreciate any comments or ideas on how to get started on this! Have a great weekend!


Attachments

  • 1.jpg
    642.8 KB · Views: 209
  • 2.jpg
    606.5 KB · Views: 199
  • 3.jpg
    529.6 KB · Views: 203
  • 4.jpg
    670.9 KB · Views: 204
  • 5.jpg
    694.3 KB · Views: 206
  • 6.jpg
    57.9 KB · Views: 205
  • G104SN03_V5_AUO.pdf
    1.9 MB · Views: 219
Upvote 0 Downvote
LVDS is a reasonably standardised protocol.
This looks like it may be what you need?


Iei Lvds-vga02-r10 18-bit Lvds To Vga Converter Board - Buy Vga Option For Dual Display Output,Lvds To Vga Converter Board Product on Alibaba.com

Iei Lvds-vga02-r10 18-bit Lvds To Vga Converter Board - Buy Vga Option For Dual Display Output,Lvds To Vga Converter Board Product on Alibaba.com
www.alibaba.com

Or a DVI-I one:

Compact-Size LVDS to DVI Converter Board with FHD Resolution Support

MSI IPC's peripherals can integrate with various modules including IPMI, TPM, power supplies, industrial graphics cards, riser cards, and the versatile rackmount/wallmount peripherals, it can help system integrators build easy-to-operate computer systems.
ipc.msi.com

DVI-I means direct connect to a DVI input monitor, and also VGA and HDMI with the appropriate pin adapters.

Upvote 0 Downvote
