PWM to Analog Converter

Discussion in 'General Electronics Chat' started by engineergc, Sep 8, 2017.

  1. engineergc

    engineergc New Member

    Joined:
    Oct 26, 2016
    Messages:
    26
    Likes:
    0
    Dear All;

    I am trying to convert PWM to analog signal without any software. I tried use RC filter but freqeuncy range of PWM signal is 5 Hz to 500 Hz, so I can not use RC filter. I searched PWM to analog converter entegres, but their minimum frequency starts from 30 Hz. How I can convert pwm to analog in specified range without any software?

  2. Pommie

    Pommie Well-Known Member Most Helpful Member

    Joined:
    Mar 18, 2005
    Messages:
    10,018
    Likes:
    317
    Location:
    Brisbane Australia
    ONLINE
    What produces PWM that varies in frequency? PWM is normally at a fixed frequency and the on/off ratio is varied. Can you give more details about the signal?

    Mike.

  3. engineergc

    engineergc New Member

    Joined:
    Oct 26, 2016
    Messages:
    26
    Likes:
    0
    I have PWM signals that have different frequencies. I want to convert them to analog signals. Min. frequency of pwm signals is 5 Hz and max. frequency is 500 Hz.

  4. dave

    Dave New Member

    Joined:
    Jan 12, 1997
    Messages:
    -
    Likes:
    0



  5. Pommie

    Pommie Well-Known Member Most Helpful Member

    Joined:
    Mar 18, 2005
    Messages:
    10,018
    Likes:
    317
    Location:
    Brisbane Australia
    ONLINE

    PWM stands for pulse width modulation, there is no variable frequency, just variable width. Unless you can describe the signal better then I can't help you - repeating your previous post doesn't help.

  6. ronsimpson

    ronsimpson Well-Known Member Most Helpful Member

    Joined:
    Apr 17, 2007
    Messages:
    7,253
    Likes:
    961
    Location:
    Loveland, CO USA
    500hz = 2mSeconds
    5hz = 2oomS
    It is possible that you have a system where the "on time" is 2mS and the off time is variable from 2mS to 200mS in 2mS steps.
    (or the reverse of that)
    _-_-_-_-_-_-=fast and high dutycycle
    _-_________-________=slow and low dutycycle
    **************OR************
    Maybe you have different PWMers. One runs at 5hz and another runs at 500hz.

  7. MikeMl

    MikeMl Well-Known Member Most Helpful Member

    Joined:
    Mar 17, 2009
    Messages:
    11,048
    Likes:
    541
    Location:
    AZ 86334
    Read this post. This is normally how you filter 500Hz PWM to produce a proportional DC level. Note the settling time. If you start with 5Hz PWM, it will take 100 times longer for the DC level to respond to a step change of the PWM duty-cycle.

  8. jpanhalt

    jpanhalt Well-Known Member Most Helpful Member

    Joined:
    Jun 21, 2006
    Messages:
    5,897
    Likes:
    502
    Location:
    Cleveland, OH, USA
    Perhaps, you really just need a frequency to voltage converter, as is sometimes used in tachometers. There are single chips to do that.

    John

  9. audioguru

    audioguru Well-Known Member Most Helpful Member

    Joined:
    Mar 16, 2004
    Messages:
    32,445
    Likes:
    936
    Location:
    Canada, of course!
    Some birds flap their wings at 5Hz.
    I agree that it will take a long time for a filter to settle when the 5Hz PWM has very narrow pulses.

  10. simonbramble

    simonbramble Active Member

    Joined:
    Nov 22, 2010
    Messages:
    430
    Likes:
    63
    this part is what you are looking for:
    http://www.linear.com/product/LTC2645

    ... although your frequency is a bit low. We designed this part for people who cannot change their software, but want an instant response DAC output instead of using a low pass filter and the inherent delay that it introduces

    • Like Like x 1
  11. ci139

    ci139 Active Member

    Joined:
    Apr 12, 2012
    Messages:
    398
    Likes:
    34
    :p:p:p:p:p:p -- a dude from linear ;););)

  12. jpanhalt

    jpanhalt Well-Known Member Most Helpful Member

    Joined:
    Jun 21, 2006
    Messages:
    5,897
    Likes:
    502
    Location:
    Cleveland, OH, USA
    Can you substantiate that claim?

    John

    • Thanks Thanks x 1
  13. schmitt trigger

    schmitt trigger Active Member

    Joined:
    May 24, 2009
    Messages:
    886
    Likes:
    84
    I believe that Simon has introduced himself previously as either a LT employee or rep.

    In any case, I have no problem with him providing suggestions. LT is a superb semiconductor company with a wide and innovative product portfolio.

  14. ci139

    ci139 Active Member

    Joined:
    Apr 12, 2012
    Messages:
    398
    Likes:
    34
    is from where you recon a true hardware engineer - all tough the app is up and running - there's a possibility it runs from the wrong bases (this' - about the nomination)
    such has happened (namely the deviceĀ“s operating range was narrow - and it didn't work because of what i thought it did) -- as there's a possibility someone passing a typo or miss wording
    (thinking of -- people who can design Op Amps are here - muhahaa - this is so sillily cool :woot:)

  15. jpanhalt

    jpanhalt Well-Known Member Most Helpful Member

    Joined:
    Jun 21, 2006
    Messages:
    5,897
    Likes:
    502
    Location:
    Cleveland, OH, USA
    Wow, what a "sentence." It is completely incomprehensible to me.

    Back to my original comment, it would help if I knew what " :p:p:p:p:p:p " and " ;););) " meant. The former apparently translates to "stick out tongue" and the latter to "wink". So, six tongues and three winks means what? How does that modify that he previously worked at Linear? Are you suggesting it is good, bad, or that his suggestion is clouded by that fact?

  16. simonbramble

    simonbramble Active Member

    Joined:
    Nov 22, 2010
    Messages:
    430
    Likes:
    63
    To be correct, I am now a dude from Analog... and no, I did not understand the sentence either (!). It sounds like an output from Google Translate. Thanks for the compliment on the product range. It is much appreciated :woot:

  17. schmitt trigger

    schmitt trigger Active Member

    Joined:
    May 24, 2009
    Messages:
    886
    Likes:
    84
    Make it three

  18. ci139

    ci139 Active Member

    Joined:
    Apr 12, 2012
    Messages:
    398
    Likes:
    34
    it's about sincere happiness . . .
    [​IMG]
    :p:p:p:p:p:p:p:p:p ! BOOM ! :) thinking of . . . centuries of pollution and contamination :woot:
    -----
    ((as in fact i think the china only should and can deal with those guys . . . in guiding their efforts to a longer perspectives ... for everyone ...))
    . . .
    as what to admire about this people is the capability to incorporate the existing no resources to actually output anything // in contrast to our plentiful world where the only brake is not getting along with each other o_O . . . continuously as and in this forum most unfortunately

    Last edited: Sep 17, 2017
  19. alec_t

    alec_t Well-Known Member Most Helpful Member

    Joined:
    Jul 10, 2011
    Messages:
    9,254
    Likes:
    1,218
    Location:
    Cardiff, Wales
    Hmm. Don't think much of their manufacturing quality control. The nose cone of the missile in that pic is way off from the template. Makes you wonder how far off target the flight end-point would be! :eek:

  20. schmitt trigger

    schmitt trigger Active Member

    Joined:
    May 24, 2009
    Messages:
    886
    Likes:
    84
    That image is inside a laboratory or building.
    Yet, Kim is wearing a heavy, fur lined coat and hat.
    There is absolutely no heating in the building!
    And that is in premier lab.

    This image is not unique. There are many pictures of Kim touring rocket and weapons labs, showing the same garments.

  21. ci139

    ci139 Active Member

    Joined:
    Apr 12, 2012
    Messages:
    398
    Likes:
    34
    v-.-v Hi! Mr. Linear-Analog-Bomb :D:D:D
    :p (too catchy not to be posted) muhahaa
